Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
|
24 1/4" x 26 3/4" |
30 5/8" x 28 3/8" |
In - Driver, Out- Passenger |
In -1 3/4", Out - 2" |
No |
N/A |
N/A |
OEM Mounting |
|
|
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
2001 - 2006
Hummer H1 |
6.5L 395ci V8, 6.6L 400ci V8 |
|
|
|
2 1/2" |
3 1/8" |
|
|
Note: Designed for Turbo Diesel |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
